High-end aura comes naturally
Displacement
Tire
Battery Capacity
| Model No. | CM150ZH-175 |
| engine | Loncin 175 air-cooled 11-pole AC |
| Spring plate | Hole diameter 800mm/width 6cm/16Kg/6 pieces |
| shock absorption | 840mm in the reinforced hole of 50/270 outer spring |
| rear axle | 180 brake caliper with full suspension and high force |
| tire | 5.00-12 |
| carburetor | PZ30 automatic air valve |
| Reverse gear | 175 Reverse gear |
| drive shaft | φ38*930 with flange |
| Brake type | Mechanical brake band with brake crossbar |
| battery | 12V9Ah |
| Vertical spring | φ10*80 outer diameter * 190 height large black vertical spring |
| Support type | Square tube top rod 700 |
| Longgu Dabang | 40*80*2.5mm |
| main beam | 40*60*3.0mm |
| Rear height of the frame | 340mm |
| Total length of the rear frame | 1600mm (front section 1375mm including flange) |
| Frame row width | 840mm |
| Rear axle center | 900mm |
| Self-flipping hole | 1580mm |
| front panel | 840/Additional welding of blocking plate |
| thrust | Great effort |
| spare tire | belt |
| Post-mortem connection | Yes, 225mm including flange |
| toolbox | Dual-armrest toolbox |
